Electric Hoist HOIST12 for 12m

356,38 zł 427,66 zł VAT included

Free delivery: Monday, 10 February

SKU 10005214-141

This electric cable hoist is suited for lifting loads, whether in the workshop, in the house or in the garden. It doesnt matter whether you want to lift building materials or car body parts, the electric cable winch is multifunctional and can be used in many ways. The weight of the unit is a light 10 kg. The assembly is quick and uncomplicated via the supplied mounting brackets. The powerful motor with 500 W power is equipped with overheating protection to prevent damage to the motor. The safety cut-out on the device ensures a shutdown as soon as the rope has been completely retracted. In order to operate the winch, it is equipped with a remote control, which is attached to the unit with a cable. There is also an emergency stop switch to stop the unit immediately in dangerous situations. The hoist lifts loads at a speed of 8 m/min (single hook) or 4,0 m/min (double hook). The winch is controlled via a remote control with a cable length of 1,6 m.

  • Load capacity (single/double hook): from 125/250 kg up to 500/1000 kg
  • Height (single/double hook): 12 m / 6 m
  • Lifting speed (single/double hook): 8 m/min 4,0 m/min
  • Rated voltage: 230 V
  • Protection class: IP54
  • Steel rope diameter: 3 mm

Technical data

General
Capacity
125/250 kg
Capacity, double cable
250 kg
Capacity, single cable
125 kg
Weight
10 kg
Sound level EN-12053
85 dB
Material
steel
Colour
Blue
Cable length
12 m
Wire cable diameter
3 mm
Power rating
S3-25%-10
ISO classification
M1
EN standard
EN14492-2
Seal
CE
IP protection type
IP54
Insulation class
B
Control cable length
1.6 m
Power cable length
0.45 m
Rated current
2.2 A
Thermal overload protection
yes
Cable strength
1870 mm
Thread size
M8
SKU
10005214-141
Brand
Pallit
Lift
Lift height
12000 mm
Lift motor power
0.5 kW
Lifting height, single cable
12 m
Lifting height, double cable
6 m
Lifting speed, single cable
8 m/min
Lifting speed, double cable
4 m/min
Battery
Battery voltage
230 V
Delivery
Delivery
Parcel service
Delivered as
parcel

Dimensions

  • Cable strength
    Capacity
    Capacity, double cable
    Capacity, single cable
    Lift height
    Weight
    Lifting speed, single cable
    Power cable length
    Free delivery
    Customer Reviews
    Price
  • 1870 mm
    125/250 kg
    250 kg
    125 kg
    12000 mm
    10 kg
    8 m/min
    0.45 m
    Monday, 10 February
    from 356,38 zł 427,66 zł VAT included
